No | Item | Standard |
1 | Leadwire dia | ∮3.18±0.05mm |
Leadwire length | 36.5±0.3mm | |
The interior height of leadwire | 9.92±0.5mm | |
External dia of shell(1) | 28.26±0.19mm | |
External dia of shell(1) | 32.57±0.19mm | |
Shell thickness | 1.75mm | |
Shell height | 9.92±0.25mm | |
Leadwire gap | 11.66±0.2mm | |
2 | Surface | Bright,clean,no burr、rusty,no glass crack and bubble |
3 | Insulation resistance | DC500v,10000M |
4 | Electrical strength | 0.5mA,AC3500V,1s |
5 | Max current | 35A |
6 | Max temperature | Subzero 35℃-125℃ |
7 | Airtightness | 4.2MPa,1m,no leakage,no deformation,no crack,leadwire no drop |
8 | Hydraulic pressure | 19.6MPa burst test,1min no leak |
9 | Leadwire strength | Axial leadwire force 148N,1m,no crack,no leakage |
10 | Heat shock | Temperature 265℃±5℃,continue 10±1S |
11 | Weld strength | Torque force no less than 30kgf/cm2 |
12 | Nickel thickness | 2-4um |
13 | Package | 100% inspection,500PCS/carton |
